R5PDM

R5PDM

7-16 DIN Male Low PIM Positive Stop™ for 7/8 in RCT RADIAX®
Radiating cable

Description

Mechanical Specifications Connector Retention Tensile Force 671.68 N   |   151 lbf Coupling Nut Proof Torque 35 N-m   |   309.776 in lb Coupling Nut Retention Force 1000 N   |   224.81 lbf Coupling Nut Retention Force Method IEC 61169-4:9.3.11 Interface Durability 500 cycles Interface Durability Method IEC 61169-4:9.5 Mechanical Shock Test Method IEC 60068-2-27 Environmental Specifications Operating Temperature -55 °C to +85 °C (-67 °F to +185 °F) Storage Temperature -55 °C to +85 °C (-67 °F to +185 °F) Attenuation, Ambient Temperature 20 °C   |   68 °F Average Power, Ambient Temperature 40 °C   |   104 °F Corrosion Test Method IEC 60068-2-11 Moisture Resistance Test Method IEC 60068-2-3 Thermal Shock Test Method IEC 60068-2-14 Vibration Test Method IEC 60068-2-6 Packaging and Weights Weight, net 229.49 g   |   0.506 lb Regulatory Compliance/Certifications Agency Classification ISO 9001:2015 Designed, manufactured and/or distributed under this quality management system
